SIMTEK simmill9W

Our revolutionary system combines the best of two worlds. It combines the advantages of a monoblock tool with the cost-effectiveness of a modular tool system. This means maximum stability and precision – with complete flexibility.

Discover simmill9W, the robust system with up to 12 cutting edges for slotting, parting and slitting with milling depths of up to 16.5 mm!

Learn more

Powerful performance and maximum efficiency.

The high-performance toothing ensures optimal power transmission at high torques and a long service life with maximum flexibility.

Would you like to learn more about simmill9W? Request a free expert consultation.

Get in touch

Milling depth

Up to 16.5 mm

Cutting
widths

From 0.5 mm to 6.0 mm

Up to 12
cutting edges

straight or crosscut

High-performance toothing

for high torque transmission

Highly precise and easy to use.

The simmill9W tool system offers extraordinary precision with the simplest of handling. The excellent concentricity and axial run-out properties enable precise cuts, while the high-performance toothing ensures easy handling and optimal power transmission.

Would you like to learn more about simmill9W?

Arrange a free expert consultation now

Request expert consultation

Your advantages:

Stable

Tools from the modular simmill9W tool system have similar performance characteristics to monoblock tools and are designed for machining with high torques, feed rates and cutting depths.

For machining companies, this means: maximum precision with more flexibility

Precise

Similar to monoblock tools, the simmill9W tool system offers outstanding concentricity and axial run-out properties for precise machining at low manufacturing tolerances.

Economical

The modular design enables a cost-efficient replacement of worn cutting inserts, while the precision-ground teeth ensure a long service life for the holders.

For machining companies, this means lower tool costs combined with maximum precision and performance.

Robust

Durable and robust: The close manufacturing tolerances used to produce simmill9W tools make the holders particularly robust and ensure a long service life even under difficult conditions.

Comparison of milling systems: (4)PSUV, simmill9W and monoblock*

The table compares different types of tooling systems and helps to categorize the simmill9W tooling system.
For more information, please contact us or download the free white paper.

PSUV**

with sintered toothing

4PSUV**

with ground toothing

simmill9W

with ground high-performance toothing

Monoblock***

Surcharge per cutting edge*

+0 €

approx. +6 €

approx. +12 €

more expensive

Power transmission

+

++

+++

++++

Holder wear

+

+++

/

Radial run-out

0,03 mm

0,015 mm

Axial run-out

0,03 mm

0,015 mm

Diameter | Teeth

up to 40 mm | 6 teeth

up to 50 mm | 12 teeth

no limit

Regrinding

no

yes

*Indicative price point. Actual prices may vary.
**Designates SIMTEK standard and customized tools in the PMX, PX, SX, UX, VX, 4U and 4V families with cutting circle diameters from 6.7 mm to 39.7 mm.
***Refers to market-standard monoblock tools with comparable cutting circle diameters to simmill9W tools.

simmill9W | Technical data

Carbide:

With internal coolant supply and shank mount
With shank diameter 15.875 mm and 16.0 mm
Usable lengths of 60.0 mm / 90.0 mm / 120.0 mm

Steel:

With internal coolant supply with shank mount
Shank diameter 19.05 mm and 20.0 mm
Usable lenght of 32.0 mm

Free White paper

Modular meets monoblock:
The Best Of Both Worlds

This white paper explains
a) the advantages of simmill9W tools over conventional circular milling systems and
a) how you can save costs by using them without having to compromise on the performance features of monoblock tools.

Downloads

The simmill 9W product catalog, data sheet and product flyer are available for download here. Select the desired document using the thumbnail to download it.

Catalog

Flyer

Contact

Do you have questions or are you interested in our product simmill9W?
Get in touch with our product experts and book a free and non-binding expert consultation!
